PL271/1 Diesel Water-Oil Separator Filter, Deutz 04504438 Engine Fuel Filter

Product Introduction

This is a domestic replacement for the Mann PL271/1 water-oil separation diesel filter. Its dimensions and performance parameters are benchmarked against Deutz OEM part numbers 04504438 and DZ04504438. Integrating dual functions of diesel filtration and water-oil separation, it effectively removes water, impurities and gums in diesel fuel. It protects precision fuel components such as injectors and high-pressure fuel pumps, reducing risks of wear, corrosion and sticking in the fuel system. Compatible with Deutz engine units, it serves as a direct replacement for OEM filters with simple installation, ideal for long-term operation of construction machinery and generator sets.

Product Advantages

1. Precisely matched OEM size with fully compatible port and installation dimensions.

2. Multi-layer composite filter media for stable water-oil separation efficiency.

3. Filter media resistant to high/low temperature and fuel corrosion, large dirt holding capacity to extend service life.

4. Premium rubber sealing components for dependable sealing and zero leakage.

5. Built-in support structure to resist pressure impact, adapted for continuous heavy-load operation of equipment.

Technical Parameters

· Filtration Accuracy: 10μm

· Filter Media: Composite glass fiber + hydrophobic polyester water-oil separation media

· Seal: Nitrile Butadiene Rubber (NBR) sealing ring

· Medium: Diesel

· Nominal Pressure: 1.0MPa

· Executive Standard: ISO 16232

Application Scope

Widely used in fuel system pretreatment for Deutz-powered construction machinery, diesel generator sets, mining equipment, heavy-duty engineering vehicles, mobile pump stations and others.
